Product Description
- The 909ECR model features a short tail swing design. On this model, if you are working in a confined space the short tail swing ensures safe and easy operation within a confined space.
- he fuel efficient, Stage IIIB / Tier 4 certified Yanmar 4TNV98C engine provides proven and reliable power.
- The hydraulic system provides a load sensing and flow sharing capability leading to operational precision, efficient performance and greater controllability.
- When it works alongside obstacles, the swing post and cylinder stay within the tracks when in an offset position, so that you can avoid the risk of damage to your machine.
- The float function can be enabled with a toggle switch on the right side of the control panel. Because you don't have to adjust the blade height during travel, cleanup and backfilling will be easier.
909ECR
Operating weight with cab
8700 kg
Engine power
46.2 kW (62.0 hp) @ 2200 rpm
Bucket capacity
0.14-0.4 m³
Maximum travel speed (High)
4.8 km/h
Maximum travel speed (Low)
2.4 km/h
Maximum swing speed
10.5 rpm
Arm breakout force
43 / 37 kN
Bucket breakout force
63 kN
Shipping length
6115 / 6200 mm
Shipping width
2400 mm
Shipping height
2710 mm
Track shoe width (std)
450 mm
Boom
3375 mm
Arm
1650 / 2100 mm
Digging reach
6847 / 7264 mm
Digging reach on ground
6651 / 7082 mm
Digging depth
4093 / 4540 mm
Vertical wall digging depth
3043 / 3963 mm
Cutting height
6724 / 7016 mm
Dumping height
4725 / 5000 mm
Minimum front swing radius
2421 mm
Dozer-up
470 mm
Dozer-down
510 mm
Swing boom left rotation
70 °
Swing boom right rotation
55 °
Model
Yanmar 4TNV98C-SLY
Emission
EU Stage IIIB / EPA Tier 4F
System maximum flow
196 L/min ( 52 gal/min)
System pressure
28 MPa
