Xiniu Hot Sale 0.8 Ton 1 Ton 1.2 Ton 1.6 Ton 1.8 Ton 2 Ton Mini Crawler Excavator
Xiniu Hot Sale 0.8 Ton 1 Ton 1.2 Ton 1.6 Ton 1.8 Ton 2 Ton Mini Crawler ExcavatorThis excavator is designed for small project, garden, farmland municipal works etc, also can be used in playground, public park. It is with small engine, simple design, easy to maintain. ModelXN08BrandOriemacOperating W......
Send Inquiry
Product Description
Xiniu Hot Sale 0.8 Ton 1 Ton 1.2 Ton 1.6 Ton 1.8 Ton 2 Ton Mini Crawler Excavator
This excavator is designed for small project, garden, farmland municipal works etc, also can be used in playground, public park. It is with small engine, simple design, easy to maintain.
| Model | XN08 |
| Brand | Oriemac |
| Operating Weight | 880kg |
| Digging bucket capacity | 0.025cbm |
| Digging bucket width | 400mm |
| Engine | KOOP(KD192) |
| Rated power | 7.6kw |
| Displacement | 6.8ml/r |
| Bore stroke | single cylinder, fan cool |
| Main pump | JINXING |
| Pump flow | 16L/min |
| Hydraulic oil tank capacity | 16.5L |
| Engine oil tank capacity | 2.8(1.3)L |
| Diesel tank capacity | 7 L |
| Working pressure | 16Mpa |
| Valve | BEIFANG |
| Swing motor | KEERSEN |
| Traveling motor | USA EATON |
| Hydraulic oil tank | 16.5L |
| Diesel oil tank | 7L |
| Arm digging force | 5.0Kn |
| Bucket digging force | 9.5Kn |
| Electric pressure | 12V |
| Electric power | 5W |
| MAIN DEMENSIONS | |
| Overall dimension( LxWxH) | 2770x896x1490 mm |
| Wheelbase | 910 mm |
| Total length of track on land | 1230mm |
| Platform ground clearance | 380 mm |
| Platform back turning radius | 784 mm |
| Chassis width | 896 mm |
| Track width | 180 mm |
| Chassis ground clearance | 132 mm |
| Track height | 320 mm |
| OPERATING RANGE | |
| Max. Digging depth | 1650 mm |
| Max. Vertical digging depth | 1375 mm |
| Max. Digging height | 2610 mm |
| Max. Dumping height | 1850 mm |
| Max. Digging radius on ground | 2850 mm |
| Min. Rotation radius | 1330 mm |
| Max. Upgrade height of bulldozer blade | 345 mm |
| Max. Digging depth of bulldozer blade | 255 mm |
