Tc Series Linear Guideway CNC Lathe with Inclined Bed Type (TC4508)
· Dealing directly with the manufacture- no middle man!· The most competitive pricing in the market.· High quality control standards, such as ISO, CE· Guaranteed delivery time.· Prompt attention to the customer inquiries.· Diverse ser......
Send Inquiry
Product Description
· Dealing directly with the manufacture- no middle man!
· The most competitive pricing in the market.
· High quality control standards, such as ISO, CE
· Guaranteed delivery time.
· Prompt attention to the customer inquiries.
· Diverse services for your needs, including sourcing other machinery, inspection goods for you by our engineers, product process tracking and good.
Features:
Cast-iron, torque-tube construction.
High-quality preloaded ball screws.
Linear guideways,
3-jaws Hydr.Chuck.
Hydr. Tool turret.
Hydr.Tail stock
Auto.Central Lubrication
· The most competitive pricing in the market.
· High quality control standards, such as ISO, CE
· Guaranteed delivery time.
· Prompt attention to the customer inquiries.
· Diverse services for your needs, including sourcing other machinery, inspection goods for you by our engineers, product process tracking and good.
Features:
Cast-iron, torque-tube construction.
High-quality preloaded ball screws.
Linear guideways,
3-jaws Hydr.Chuck.
Hydr. Tool turret.
Hydr.Tail stock
Auto.Central Lubrication
| TC Inclined Bed Turning Center With Linear Motions | |||||
| Specifications | TC4508 | TC4516 | TC4525 | TC4532 | TC4545 |
| Control | Siements802D | Siements802D | Siements802D | Siements802D | Siements802D |
| Price | 28 | 35.5 | 36 | 36.5 | 38 |
| Bed incline | 45 | 45 | 45 | 45 | 45 |
| Cutting length | 250mm | 300mm | 400mm | 580mm | 1000mm |
| Cutting capacity over bed | Φ300mm | Φ160mm | Φ250mm | Φ320mm | Φ450mm |
| Cutting capacity over support | Φ320mm | Φ200mm | Φ280mm | Φ390mm | Φ500mm |
| Headstock/Spindle | |||||
| Chuck Size | A2-4 | A2-5 | A2-6 | A2-8 | A2-8 |
| Spindle power | 5.5KW | 5.5KW | 5.5(7.5KW) | 7.5KW | 11KW |
| Spindles used | IBAG | ||||
| Spindle speed | 4500rpm | 4500rpm | 4500rpm | 2000rpm | 2000rpm |
| Spindle bore | Φ50mm | Φ50mm | Φ50mm | Φ82mm | Φ82mm |
| Through spindle Draw tube bore | Φ40mm | Φ40mm | Φ40mm | Φ72mm | Φ72mm |
| Rapid feed | 18m/min | 18m/min | 18m/min | 18m/min | 18m/min |
| X/ZTravel | |||||
| X axis programmable stroke | 250mm | 110mm | 150mm | 200mm | 320mm |
| Z axis programmable stroke | 250mm | 300mm | 400mm | 580mm | 1000mm |
| X/Z motor | AC1.0KW | AC1.0KW | AC1.5KW | AC2.2KW | AC3.7KW |
| Turret positions | Collect kit | 8 | 8 | 10 | 10 |
| Direction of rotation | Bi-directional | ||||
| Standard section of tooling tool | 20×20mm | 20×20mm | 20×20mm | 25×25mm | 25×25mm |
| Standard diameter of boring bar | Φ25mm | Φ25mm | Φ32mm | Φ40mm | Φ40mm |
| Tool Change time | - | 0.35 | 0.35 | 0.3 | 0.3 |
| Tailstock quill | - | Φ65mm | Φ65mm | Φ100mm | Φ100mm |
| Tailstock quill travel | - | 80mm | 80mm | 120mm | 120mm |
| Stroke travel | - | 300mm | 500mm | 580mm | 1000mm |
| Tailstock taper | - | 4# MT4 | 5# MT5 | ||
| Positioning accuracy | 0.01 | 0.01 | 0.01 | 0.01 | 0.01 |
| Repeatability accuracy | 0.008 | 0.008 | 0.008 | 0.008 | 0.008 |
| Overall dimensions | 1.51*1.07*1.12m | 2.2*0.89*1.46m | 2.32*1.0*1.53m | 2.58*1.04*1.64m | 3.17*1.1*2.5m |
| weight | 3000kg | 4000kg | 5000kg | 5500kg | 7000kg |
