Elevator Rotary Head PE Film Blowing Machine for Plastic Bag
film blowing machine manufacturing machine Model number: MD-HL ( Elevator Rotary head Pe Film Blowing Machine ) Product of polyethylene film extruder: HDPE/LDPE/LLDPE film Application of polyethylene film extruder: - T-shirt bags - Garbage bags - Furniture cover films - Laundry bags Material ......
Send Inquiry
Product Description
film blowing machine manufacturing machine
Model number: MD-HL ( Elevator Rotary head Pe Film Blowing Machine )
Product of polyethylene film extruder: HDPE/LDPE/LLDPE film
Application of polyethylene film extruder:
- T-shirt bags - Garbage bags
- Furniture cover films - Laundry bags
Material of polyethylene film extruder:
- Recycled material - LDPE/LLDPE blend
- HDPE with CaCO3 - Biodegradable or virgin raw material
USE:
1.Material: LDPE. HDPE. LLDPE, which are widely used for packing liquid, printed base material, products for export and industrial products.
2. double layer co-extrusion laminated film can prolong the length for preservation of liquid package.
3. the cylinder and screw stem of the extruder are made of high quality alloy steel with optimum hardness and durable service after precision finishing and nitrogen treatment.
4. the auxiliary machine has a platform working table for making operation easy and is equipped with bubble stabilizing ring.
5. double rolling and double cutting with torque motor to keep proper tensions and make rolling even and roll changing easy.
6. Optional equipment
Double winder
Rotary die head
Auto loader
Double lip air ring
Air shaft
Corona treatment
Fast screen changer
Air compressor
All roller pneumatic type
MD-HL series elevator Rotary PE film blowing machine | ||||
Main Technical Parameters | ||||
Model | MD-HL50 | MD-HL55 | MD-HL60 | MD-HL65 |
Suitable Material | LDPE LLDPE HDPE | |||
Max Film Width(mm) | 600 | 800 | 1000 | 1200 |
Film Thickness(mm) | LD:0.02-0.15 HD:0.02-0.15 | |||
Max Extrusion Output HD LD
| 40kg/hr 50kg/hr
| 50kg/hr 60kr/hr | 60kg/hr 70kg/hr | 80kg/hr 100kg/hr |
Extrusion unit | ||||
Gear Box | 146 | 173 | 173 | 200 |
Screw Diameter(mm) | φ50 | φ55 | φ60 | φ65 |
Screw L/D Ratio | 28:1 | |||
Screw's Material | 38 CRMOALA | |||
Barrel's Material | 38 CRMOALA | |||
Barrel's Cooling Fan | 250W×2 | 370×2 | 370×2 | 370*2 |
Thermo Control (zone) | 3 | 3 | 3 | 4 |
Driving Motor (kw) | 11 | 18.5 | 22 | 30 |
Extrusion Die | ||||
Die Size (mm)HD LD | HD:φ60 LD: φ150 | HD:φ80 LD: φ180 | HD:φ100 LD: φ220 | HD:φ120 LD: φ250 |
Rotary Die Head | 360°Continue Rotary | |||
Thermo Control (zone) | 2 | 2 | 2 | 2 |
Air Ring | 1PCS | |||
Cooling Blower (kw) | 1.5 | 2.2 | 2.2 | 3 |
Take-UP Unit | ||||
Roller Width (mm) | φ138*650 | φ138*850 | φ138*1100 | φ138*1300 |
Take-UP Motor (kw) | 0.75 | 1.1 | 1.1 | 1.5 |
Take-UP Speed(M/min) | 10-60 | 10-60 | 10-60 | 10-60 |
Winding Unit | ||||
Type OF Winder | Surface Friction Double Winders | |||
Roller Width (mm) | 700 | 900 | 1100 | 1300 |
Winding Motor | 16N.M | 10N.M | 10N.M | 16N.M |
Winding Speed(M/min) | 10-60 | 10-60 | 10-60 | 10-60 |
Voltage | 380V 50Hz 3PHASE | |||
Cover Dimensions (m) | 4.5*2.0*4.3 | 4.5*2.2*4.5 | 5*2.5*4.8 | 5.5*2.8*5.2 |
price | ||||
OPTIONAL EQUIPMENT |
|
|
| |
1)AUTO LOADER×2PCS |
|
|
| |
2)AIR COOLING DEVICE |
|
| ||
3)CORONA |
|
|
| |
4)MANUAL MECHANICS SCREEN CHANGER×2 |
| |||
5)FULL AUTOMATIC WINDER |
|
| ||
6)Embossing Roller |
|
| ||
1.Installation Services
Installation Services are available with all new machine purchases. We will provide the technical know-how for your operation smooth transition and support for installing, debugging, operation of the machine, it will indicate you how to use this machine well.
2.Clients Traning Services
We can train your staff to use your film blowing equipment systems properly.It means that we offer Customers Training, teaching how to use the systems most efficiently and safely as well as how to maintain optimal operational productivity.
3.After Sales Service
We offer the Preventative Maintenance and After Sales Service. For we strongly feels about the importance of supporting our customers and the product solutions we provide.Consequently we offer comprehensive maintenance options to prevent equipment issues before they become problems. Also we offer one year guarantee period.
In one words,your satisfication is our persuit forever!
Ruian Mingde Machine Co.,Ltd,is a professional manufacturer ,specialized in the making of plastic bag making machine , film blowing machine,printing machine ,plastic recycling machine and so on. And our machine is all in good quality and the price is very competitive in China.
1. ISO 9001: 2000, GSG, SGS, CE, Production Assessment, Gold Supplier certificated
2. All machines will be examined and tested before delivery by 5 professional engineers (with more than 15 years machine experience)
3. Perfect after-sale system: We have more than 5 experienced technicians work abroad.
4. Yearly Production Capacity -- 200-300 sets
5. Prompt Reply Within 12 Hours
