Wood Sawdust Making Machine for Pallet Blocks
Sawdust crusher introduction:sawdust crusher is to crush wood logs,wood lumps,wood branches,tree roots,straw,salks and so on into small pieces. There are two feed inlets for materials of different sizes.It is mainly consisted of upper&lower engine body, side discharging outlet, centre rotor, low......
Send Inquiry
Product Description
Sawdust crusher introduction:
sawdust crusher is to crush wood logs,wood lumps,wood branches,tree roots,straw,salks and so on into small pieces.
There are two feed inlets for materials of different sizes.
It is mainly consisted of upper&lower engine body, side discharging outlet, centre rotor, low
pressure fan, underframe etc.
It is an ideal equipment in line of producing various wood products such as wood blocks, wood pellets, biomass briquette etc.
Sawdust crusher features:
Double layer case, external case is made of thicken steel plate, interior
case is made of wear-resistant scale board.
2. Center rotor is made of moving blade, fixed blade, main axis and axis pin.
3. Compact structure, easy operation, high efficiency.
4. Automatic feed system can be added according to customer`s demands.
Sawdust crusher parameters:
Type | YSC-600 | YSC-800 | YSC-900 | YSC-1000 | YSC-1200 |
Power(kw) | 22+4 | 30+5.5 | 37+7.5 | 45+11 | 55+11 |
Rotating Speed(h/min) | 2600 | 2600 | 2400 | 2400 | 2400 |
Capacity(kg/h) | 800-1200kg | 1800-2000kg | 2000-3000 kg | 3000-4000 kg | 4000-6000kg |
Feeding size | According to your materials | ||||
Weight(kg) | 1300 | 2000 | 2800 | 3500 | 4500 |
Dimensions(m) | 2.5x2.0x1.2 | 2.6x2.1x1.5 | 2.8x2.2x1.5 | 3.0x2.5x1.7 | 3.4x2.8x2 |
