Plastic Cup Making Machine for Round Square PP Pet Mould

Product Description

Cup making machine is the most ideal equipment for the production of disposable plastic products:disposable cup / bowl / boxes and plastic packaging products by changing the mold

Properties: the cup making machine is mainly used for the production of disposable plastic containers: such as cup, drink cup, jelly cup, yogurt cup, bowl, bowl of instant noodles, packing box, plastic cup lid, and fruit tray. Medicine, light industry and textile, tourism, toys and other related plastic packaging products.

Features:
1, high efficiency, energy saving, safety, environmental protection and high qualified rate of finished products.

2, the whole set of send pieces, heating, stretching, forming, cutting edge, blowing cup, waste winding, one-time completion, greatly saves labor costs, improve product profits.

3, stable operation, small noise, clamping force, high rate of finished products.

4, the whole machine is controlled by PLC touch screen, and the operation is simple and convenient. The cam runs smoothly, firm and durable, and the production speed is fast. Different plastic products can be produced by installing different moulds, so as to achieve the purpose of one machine and multiple purposes.

5, raw materials to adapt to a wide range, such as PS, PP, PVC, PET, ABS and other plastic sheeting can be processed.

Molding area(mm²)	650×330
Sheet width(mm)	500 - 660
Sheet thickness(mm)	0.3-2.0
power(kw)	30
Molding depth(mm)	160
output(p/min)	15-25
Air pressure(mpa)	0.7
Water consumption(m³/h)	0.5
Main machine rate(kw)	5.5
Main machine dimension(L×W×H)(mm)	3500×1800×2500
Main machine weight	4 ton
Voltage 3 phrase 4 stage	380V±15V
