Oriemac Construction Machinery 5ton Wheel Loader Zl50gn for Sale
Construction Machinery 5ton Wheel Loader Zl50gn for SaleFeature:Heavy load for the rocky condition; the working device and front and rear frame feature thick board of high strength, reasonable distribution and strong carrying capacity. The large rock bucket with capacity of 3.0m³ is improve......
Send Inquiry
Product Description
Construction Machinery 5ton Wheel Loader Zl50gn for Sale
Feature:
Heavy load for the rocky condition; the working device and front and rear frame feature thick board of high strength, reasonable distribution and strong carrying capacity.
The large rock bucket with capacity of 3.0m³ is improved in terms of the work efficiency and adaptation. The bucket teeth adopt the structure of toothholder and sleeve. The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.
Main Specification:
1. Model: ZL50GN
2. Shangchai engine SC11CB220G2B1 under Caterpillar C6121 license
3. Rated Power: 162kW/2200r/min
4. Rated load: 5 ton
5. Planetary power shift transmission
6. Arvin Meritor dry brake axle
7. Hydraulic pilot control system
8. Cooling and heating air conditioner standard cab
9. 3.0m3 standard bucket
10. 23.5-25-16PR tires
11. Operating weight: 17500kg
12. Dimensions: 8165x3016x3485mm
Parameter:
Photo Show:
About US
Feature:
Heavy load for the rocky condition; the working device and front and rear frame feature thick board of high strength, reasonable distribution and strong carrying capacity.
The large rock bucket with capacity of 3.0m³ is improved in terms of the work efficiency and adaptation. The bucket teeth adopt the structure of toothholder and sleeve. The cutting blade and bucket edge are equipped with protection device, featuring excellent abrasion resistance and shock resistance.
Main Specification:
1. Model: ZL50GN
2. Shangchai engine SC11CB220G2B1 under Caterpillar C6121 license
3. Rated Power: 162kW/2200r/min
4. Rated load: 5 ton
5. Planetary power shift transmission
6. Arvin Meritor dry brake axle
7. Hydraulic pilot control system
8. Cooling and heating air conditioner standard cab
9. 3.0m3 standard bucket
10. 23.5-25-16PR tires
11. Operating weight: 17500kg
12. Dimensions: 8165x3016x3485mm
Parameter:
| ZL50GN WHEEL LOADER PARAMETER | ||
| Description | Specifications | |
| Bucket capacity | 3.0 m3 (Standard bucket )/ 2.5 m3 (rocket bucket ) | |
| Rated load | 5000 kg | |
| Dumping clearance | 3090 mm | |
| Dumping reach | 1130 mm | |
| Max. breakout force | 170 kN | |
| Dimenison L*W*H | 8165×3016×3485 mm | |
| Operating weight | 17500 kg | |
| Raising time | ≤6S | |
| Total cycling time | ≤11S | |
| Max drawing force | 165±5 KN | |
| Articulated angle | ±35% | |
| Min. turning radius | 6400 mm | |
| wheel base | 3300 mm | |
| Tread | 2250 mm | |
| Travelling peed | 1st(F/R) | 11.5/16.5 KM/H |
| 2nd(F) | 38 KM/H | |
| Engine model | Shangchai engine SC110B220G2B1 | |
| 162/2000 kW/r/min | ||
| Tyre | 23.5-25-16PR | |
Photo Show:
