Product Description

Mini Wheel Skid Steer Loader For Sale CLG764

Product Description

Reliable engine and wet axles. Frame designed for high resistance and efficient load distribution ensuring longer life.
Digging force increased by 10% along with increases in digging depth and minimum turning radius.
Tandem gear pump enables fine grading and has flow control via dashboard switch. Power assisted service brakes reduces fatigue.
Spacious Cab offers wide range of view. More ergonomically designed handrail and steps for safe and easy entry/exit.
Open front grill gives easy access for cooling system cleaning which is great for dusty conditions, battery access and electric maintenance.

Main Parameter

Gross Power	75 kW (102 hp) @ 2200 rpm
Net Power	72 kW (98 hp) @ 2200 rpm
Operating Weight	8600 kg
Maximum Digging Depth	4440 mm
Maximum speed	9.8 - 44 km/h
Turning Radius Outside of Front Tire w/o single braking	4800 mm
Turning Radius Outside of Bucket w/o single braking	/ mm
Turning Radius Outside of Front Tire w/ single braking	/ mm
Bucket Breakout Force, General bucket	52.1 kN
Bucket Digging Force	52.1 kN
Maximum Dump Height (Loading)	2691 mm
Loading Height (Digging)	3586 mm
Model	YC4A105Z-T20
Emission Standard	EPA Tier 2 / EU Stage II
Standard Bucket Heaped Capacity	1 m³
Standard Backhoe Bucket Heaped Capacity	0.2 m³
