Product features: laser cutting machine 1410/acrylic photo frame/Laser cutter glass engraver 1.NC series of laser engraving cutting machines adopt new type,hi-speed laser tube,which make beam more stable than common laser tube,the service life of the laser tube can reach 1000 ......
Product features: laser cutting machine 1410/acrylic photo frame/Laser cutter glass engraver
1.NC series of laser engraving cutting machines adopt new type,hi-speed laser tube,which make beam more stable than common laser tube,the service life of the laser tube
can reach 1000 hours.
2.Compared with common laser engravers,QL series of laser engravers adopt more specific design of machine-body,higher strength steel frame structure,which make strength forty percent more higher,never deformable.
3.Humanized and most modernized design of appearance reflects caring idea of QILI,it is simple to operate
and maintenance.
4.Advanced DSP control system and special motion control ship make the machines cut curve continuously
and rapidly,the selection function of the shortest path makes efficiency higher.
5.All machined are configurated with U-disk offline control system,so it is more simple and easier to operate.
6.The red-light positioning device can indicate process site of laser head to avoid trouble of manual position.
1400x1000mm Laser engraving Machine| Laser type | Hermetic and detached CO2 |
| Working area | 1400mmx1000mm |
| Laser power | 80w(100/130/150w for option) |
| Control system | Ruida or Leetro |
| Driver and motor | Leadshine driver and motor |
| Transmission | Hiwin square rail and high quality belt |
| Lens and mirror | Imported from Singapore |
| Work table | Honey comb or blade |
| Red dot position | With |
| Machine color | White and blue or black and red |
| Delivery time | 10 days |
| Payment | T/T; L/C; Western Union |
| Cooling mode | Circulating-water-cooling |
| Power adjusting | 0-100%controlling,adjusting by software |
| Max engraving speed | 60m/min |
| Max cutting speed | 50m/min |
| Repeating location | ±0.01mm |
| Minimum Character | Chinese character 1.5mm, christcross-row 1mm |
| Working voltage | AC220V 50/60HZ |
| Body dimension(L*W*H) | 2000*1460*1110mm |
| Packing | Export wooden case |
| Gross weight | 515kgs |
| Working environment | Temperature: 0-45,Humidity: 5%-95% |
| Controlling software language | Chinese, English, French, Russian, Portuguese, Turkish, German |
| Dictate format | *.plt,*.dst,*.dxf,*.bmp,*.dwg,*.al,*las, Support AutoCAD, CoreDraw direct outputting |
| Optional Equipment | |
| Optional | Rotary axis |
| Up down table | |
| Water chiller | |
| CCD camera | |
